OUR EQUIPMENT
Our lab facilities include state-of-the-art tools to undertake experiments the fields of ultrafast light (LaserLab) and quantum matter (QMADE Lab). Moreover, we offer a wide range of services associated with these equipment to the scientific community.
A list of tools, services, fares and the procedure to access them is described below (information in spanish can be found here).
LIGHT SOURCE CHARACTERIZATION
INSTRUMENT:
Optical microscope (Zeiss, Axio Imager Z1m)
INSTRUMENT:
Laser fume extraction systems
PROCESSING OF MATERIALS USING LIGHT SOURCES
INSTRUMENT:
Ti:sapphire laser (60 fs, 5 kHz, 800 nm) coupled to a micro-processing stage (3 axes: XYZ). Other wavelengths available: 400 nm and 266 nm.
RELATED SERVICES:
- Micro and nanostructuring of materials with ultrashort laser pulses.
- Time resolved spectroscopy / lifetime measurements of samples.
INSTRUMENT:
Ti:sapphire laser (60 fs, 5 kHz, 800 nm) coupled to a micro-processing stage (6 axes: XYZ, tip-tilt-rotation).
RELATED SERVICE:
Manufacturing of photonic devices: waveguides, optical circuits and integrated lasers.
INSTRUMENT:
Andor Kymera 328i Spectrograph with iCCD Andor iStar 334T. Gratings 150, 600 y 1200 lin/mm.
RELATED SERVICES:
- LIBS spectrometry of materials: elemental analysis (heritage objects, multilayer materials, etc.) and depth profiling.
- Time resolved spectroscopy / lifetime measurements of samples.
FABRICATION AND ASSEMBLY OF ATOMICALLY THIN MATERIALS
INSTRUMENT:
Transfer system and 4-axis micromanipulators (XYZ and θ).
RELATED SERVICE:
Van der Waals staking of 2D materials with precision on micro-positioning and twist-angle control between layers.
INSTRUMENT:
Spin coater SPS Polos SPIN150i.
RELATED SERVICE:
Spin coating of thin films.
INSTRUMENT:
Quartz tube furnace/annealer.
RELATED SERVICE:
Thermal annealing up to 550 °C.
INSTRUMENT:
Home-made Projection Mask-Less Lithography.
RELATED SERVICE:
Optical lithography.
INSTRUMENT:
Glove Box station.
RELATED SERVICE:
For exfoliation and assembly in dry, inert atmosphere of 2D materials sensitive to moisture and oxygen.
INSTRUMENT:
Plasma cleaner Henniker HPT-100.
RELATED SERVICE:
Plasma cleaning or surface activation via O₂/Ar gases.
INSTRUMENT:
Ultrasonic bath RS Pro 100W.
RELATED SERVICE:
Ultrasonic bath for sample preparation.
More information about the instrument here.
INSTRUMENT:
Motic BA310 MET-H Trinocular (Upright image)
RELATED SERVICE:
Optical Microscope
CHARACTERIZATION OF ELECTRO-OPTIC MATERIALS AND DEVICES
INSTRUMENT:
FTIR Spectromenter Vertex v70.
RELATED SERVICE:
FTIR spectra in transmission and reflection (50-8000 cm-1) in air and vacuum.
INSTRUMENT:
Sub-Terahertz sources.
RELATED SERVICE:
Tunable sub-THz sources from 0.75 – 0.3 THz.
INSTRUMENT:
Turnkey DFB Quantum Cascade Laser, 9 – 10 µm.
RELATED SERVICE:
CWL Quantum Cascade Laser with output power >5mW at 9-10 µm.
INSTRUMENT:
Bluefors cryogen-free Dilution Refrigerator LD 400.
RELATED SERVICE:
Dilution cryostat (7mk – 100mK ) with 3D vector magnet up to 7T and optical ports from Visible to THz.
INTERESTED IN OUR SERVICES? E-mail us at lumes@usal.es
